Projection Distance
| Display size (16:9) | Projection distance | |||
|---|---|---|---|---|
| Screen diagonal ( inch ) |
W (mm) | H (mm) | Wide (m) | Tele (m) |
| 60 | 1,328 | 747 | 1.78 | 3.66 |
| 70 | 1,549 | 872 | 2.09 | 4.28 |
| 80 | 1,771 | 996 | 2.40 | 4.89 |
| 90 | 1,992 | 1,121 | 2.70 | 5.51 |
| 100 | 2,214 | 1,245 | 3.01 | 6.13 |
| 110 | 2,435 | 1,370 | 3.31 | 6.75 |
| 120 | 2,656 | 1,494 | 3.62 | 7.36 |
| 130 | 2,878 | 1,619 | 3.92 | 7.98 |
| 140 | 3,099 | 1,743 | 4.23 | 8.60 |
| 150 | 3,320 | 1,868 | 4.53 | 9.22 |
| 160 | 3,542 | 1,992 | 4.84 | 9.84 |
| 170 | 3,763 | 2,117 | 5.14 | 10.45 |
| 180 | 3,984 | 2,241 | 5.45 | 11.07 |
| 190 | 4,206 | 2,366 | 5.75 | 11.68 |
| 200 | 4,427 | 2,490 | 6.06 | 12.30 |
- * Projection distances are design specifications, so there is ±5% variation.
Lens Shift Function
Specifications
| DLAX9 | DLA-X7 | DLA-X3 | ||
| Device | 0.7-inch D-ILA x3 | |||
| Resolution | Full HD D-ILA device (1920 x 1080) | |||
| Lens | 2 x motorised zoom / focus | |||
| f=21.4mm - 42.8mm | ||||
| F=3.2 - 4 | ||||
| Projection size | 60 - 200 inches (screen diagonal) | |||
| Lens shift | function +/-80% Vertical and +/-34% Horizontal (motorised) | |||
| Light source Lamp | 220W Ultra-High Pressure Mercury Lamp (lamp life: approx. 3,000 hours in Normal mode) | |||
| Brightness | 1,300lm | |||
| Contrast ratio | Native: 100,000:1 | Native: 70,000:1 | Native: 50,000:1 | |
| Input terminals | Component | 1(RCA; Y , PB/CB , PR/CR) | ||
| HDMI | 2 (ver.1.4a, 3D, Deep Colour CEC compatible) | |||
| Analogue RGB (PC) | 1 (D-sub 15-pin) | 1 (D-sub 15-pin) | - | |
| Output terminals | Trigger | 1 (mini jack, DC12V/100mA) | ||
| 3D sync | 1 (mini DIN 3-pin) | |||
| Control terminals | RS232C | 1 (D-sub 9-pin) | ||
| Remote | 1 (mini jack) | |||
| LAN(RJ45) | 1 | 1 | - | |
| Video input signal | Digital | 480i/p, 576i/p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 |
||
| Analogue | 480i/p, 576i/p, 720p 50/60, 1080i 50/60 | |||
| PC input signal | HDMI | VGA, SVGA, XGA, WXGA, WXGA+, SXGA, WSXGA+, WUXGA | ||
| Analogue RGB (D-sub 15-pin) |
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, WSXGA+, 1920 x 1080, MAC 13", 16", 19" | VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, WSXGA+, 1920 x 1080, MAC 13", 16", 19" | – | |
| 3D format | Frame packing | 1080p 24, 1080i 50/60, 720p 50/60 | ||
| Side-by-side | 1080p 50/60, 1080i 50/60 | |||
| Top and bottom | 1080p 24, 720p 50/60 | |||
| Noise level | 20dB (in Normal mode) | |||
| Power requirement | AC 110V-240V, 50/60 Hz | |||
| Power consumption | 350W (Stand-by: 0.9W) | |||
| Dimensions (W x H x D, mm) | 455 x 179 x 472 | |||
| Weight, kg | 15.1 | 15.1 | 14.7 | |
External Dimensions
Terminals on the rear ( DLA-X9 / DLA-X7)
Terminals on the rear ( DLA-X3)
Optional Accessories
3D Glasses
PK-AG1-B
3D Synchro Emitter
PK-EM1
User-replaceable Lamp
PK-L2210U
- The projector is equipped with a ultra-high pressure mercury lamp, which may break, emitting a loud noise, when it is subjected to shock or after it has been used for some length of time.
- Please note that, depending on how the projector is used, there can be considerable difference between individual lamps regarding how many hours they will operate before requiring replacement.
- An additional payment is required for installation of a new lamp, if necessary.
- The projector lamp requires periodic replacement and is not covered by warranty.
- Please be aware that, because the D-ILA device is manufactured using highly advanced technologies, 0.01% or fewer of the pixels may be non-performing (always on or off).
Design and specifications are subject to change without notice.
All pictures on this brochure are simulated.
